Application
Pump developed to cover various applications and for use with various fluids, with various viscosity and pressure conditions. Main application with Boilers and Burners with low pressure transfer (also installed on the SPB double station) to medium-pressure Burner, in the same configuration, ideal for small Oil systems (lubrication, Pre-heating, etc…)
Pump Series – PB SERIES
Operating Parameters
Flow rate between 3 and 41 lpm
Delivery pressure 40 barg (581 psi) MAX
Operating temperature between 0 and 150°C
Viscosity range between 1.2 and 5000 cSt
Speed between 750 and 3600 rpm
Typical Liquids
Fuels (HFO, LFO,MGO,DO,LSMGO); Mineral and synthetic lubricating oil;
Application
This pump is designed to help solve problems in the ENGINE ROOM. Developed to fulfil new regulations on the environment, consumption and emissions. Technically developed to extend maintenance intervals and to operate with fluids with completely diverse viscosities and properties, from LSMGO to HFO. Its standard configuration uses MAGNETIC DRIVE couplers.
Pump Series – PHS SERIES
Operating Parameters
Flow rate between 6 and 200 lpm
Delivery pressure 16 barg (233 psi) MAX
Operating temperature between 0 and 150°C
Viscosity range between 1.2 and 5000 cSt
Speed between 750 and 3600 rpm
Typical Liquids
Fuels (HFO, LFO,MGO,DO,LSMGO); Mineral and synthetic lubricating oil
Application
Featuring a solid and sturdy design, developed from the Heavy Duty Industry version and optimised to transport fluids with completely diverse viscosities and properties, from LSMGO to HFO, this pump is also frequently used in Diesel Engine, Thruster and Reduction Gear lubrication systems. Body also available in Grey cast iron (UNI EN 1561:2011 EN-GJL-250) and Nodular cast iron (UNI EN 1563:2011 EN-GJS-400).
Pump Series – PZ SERIES
Operating Parameters
Flow rate between 20 and 5400 lpm
Delivery pressure 16 barg (233 psi) MAX
Operating temperature between 0 and 150°C
Viscosity range between 1.2 and 5000 cSt
Speed between 750 and 3600 rpm
Typical Liquids
Fuels (HFO, LFO,MGO,DO,LSMGO); Mineral and synthetic lubricating oil
Application
An extension of the PZ series range, the same configuration with in-line ports and nodular cast iron body (UNI EN 1563:2011 EN-GJS-400), capable of reaching a flow rate of 600m3/h. Standard applications: loading pumps, transfers and large-scale lubrication. The pump is designed for either vertical or horizontal installation options.
Pump Series – PZD SERIES
Operating Parameters
Flow rate between 1400 and 10000 lpm
Delivery pressure 16 barg (233 psi) MAX
Operating temperature between 0 and 150°C
Viscosity range between 1.2 and 5000 cSt
Speed between 750 and 3600 rpm
Typical Liquids
Fuels (HFO, LFO,MGO,DO,LSMGO); Mineral and synthetic lubricating oil
Application
This pump is typically used with lubrication systems, optimised to operate in very adverse fluid and ambient temperatures (very low) and start-up viscosities (high), developed directly from decades of experience in sectors such as reduction gear and windmill blade lubrication and Thruster lubrication for ships and platforms.
Pump Series – PXF SERIES
Operating Parameters
Flow rate between 10 and 5400 lpm
Delivery pressure 30 barg (436 psi) MAX
Operating temperature between 0 and 120°C
Viscosity range between 10 and 5000 cSt
Speed between 750 and 3600 rpm
Typical Liquids
Mineral and synthetic lubricating oil
Application
Used with low-viscosity fluids such as LSMGO and light gas oils with standard viscosities between 1.2 cSt and 10/15 cSt, typically used with Boiler systems with pressures up to 40 bar and flow rates of 560l/min (33.6m3/h). Its high self-priming strength and its capacity to operate at low viscosities make it very a suitable pump for applications with fluids that do not include lubricating properties among its main characteristics.
Pump Series – PO PWO SERIES
Operating Parameters
Flow rate between 10 and 650 lpm
Delivery pressure 100 barg (1451 psi) MAX
Operating temperature between 0 and 100°C
Viscosity range between 1 and 400 cSt
Speed between 2900 and 3600 rpm
Typical Liquids
Mineral and synthetic lubricating oil
Application
The standard version with aluminium body and nitrided steel screws, the ideal combination of materials to make these pumps very suitable for working with any mineral oil or lubricating oil in a broad range of conditions including heavy duty, up to operating pressures of 120 bar, for Deck Machinery and Propellers. A range extension is available up to 1,300l/min (78m3/h).
Pump Series – POF PWOF SERIES
Operating Parameters
Flow rate between 11 and 850 lpm
Delivery pressure 120 barg (1741 psi) MAX
Operating temperature between 0 and 120°C
Viscosity range between 10 and 5000 cSt
Speed between 1450 and 3500 rpm
Typical Liquids
Mineral and synthetic lubricating oil
Application
twin-screw pump WITH timing gears, suitable for various types of fluids, also containing impurities, also available made entirely of stainless steel, also available in version fulfilling regulations API676 IIED and IIIED.
Pump Series – 2SP SERIES
Operating Parameters
Flow rate between 10 and 1000 lpm
Delivery pressure 10 barg (146 psi) MAX
Operating temperature between 0 and 300°C
Viscosity range between 1.2 and 5000 cSt
Speed between 750 and 3600 rpm
Typical Liquids
Mineral and synthetic lubricating oil
Application
twin-screw pump WITH timing gears, suitable for various types of fluids, also containing impurities, also available made entirely of stainless steel, also available in version fulfilling regulations API676 IIED and IIIED.
Pump Series – 2SP LS SERIES
Operating Parameters
Flow rate between 10 and 20000 lpm
Delivery pressure 40 barg (581 psi) MAX
Operating temperature between 0 and 300°C
Viscosity range between between 1 and 15000 cSt
Speed between 750 and 3600 rpm
Typical Liquids
Fuels (HFO, LFO,MGO,DO,LSMGO); Mineral and synthetic lubricating oil
